Customizable JUTAI Automatic Gate Photocell IR Beams For Gates

Name: Customizable JUTAI Automatic Gate Photocell IR Beams For Gates
Brand: JUTAI
Price: 1 USD

Brand Name : JUTAI

Model Number : IR-20

Certification : CE

Place of Origin : China

MOQ : 1

Price : Negotiation

Payment Terms : T/T, L/C, D/A, D/P, Western Union, Paypal, , MoneyGram, Alipay

Supply Ability : 1000 pieces per month

Delivery Time : 5 - 8 working days

Packaging Details : Cartoon

IP Rating : IP65

HS Code : 8531901000

Package Size : 12.00cm * 11.70cm * 4.30cm

Package Gross Weight : 0.150kg

Detection Type : Photon Detector

Type : Wired

Contact Now

Customizable JUTAI Hot Sale Automatic Gate Infrared Photocell Beam Sensor With 30m

The JUTAI IR-20M Infrared Beam Sensor is a cutting-edge solution for reliable detection in various applications. Here's a detailed overview of its features, installation instructions, and applications:

Features:

Long-Distance Detection: Can detect objects up to 30 meters away, even in outdoor sunlight.
High Sensitivity: Capable of accurately detecting small objects or subtle movements.
Fast Response Time: Provides quick detection, ideal for applications requiring rapid response.
High Interference Resistance: Resistant to environmental light interference, ensuring stable performance.
Easy Installation: Designed for easy setup and alignment, simplifying user installation and maintenance.

Applications:

Automatic Doors and Access Control Systems: Detects people or vehicles passing through, controlling door opening and closing.
Security Systems: Detects unauthorized entry, commonly used for perimeter, window, and door security.
Industrial Automation: Used in production lines and conveyor belts to detect object positions and movements, controlling machinery operations.
Parking Management: Detects vehicle entry and exit in parking lots, controlling barrier gates or monitoring parking space occupancy.

Installation Instructions:

Access the Interior: Open the front panel of the photocell to access its components.
Cable Insertion and Base Fixation: Insert cables into slots and securely fix the base to the wall.
Mounting: Drill holes for wall or metal surface mounting and insert suitable screws.
Make Connections: Connect cables and power the photocell with 12-24V DC/AC voltage.
Proper Positioning: Align the photocell properly, ensuring the red LED on the receiver remains off when aligned correctly.
Replace Front Panel: Once connections are verified, replace the front panel securely.
Test System: Interrupt the infrared beam to check relay response.
Secure Front Panel: Finally, secure the front panel with provided screws.

Experience Top-Tier Reliability:

Stable Detection Distance: Offers stable detection over 20 meters.
High-Quality Infrared Lamps: Utilizes renowned German brands for consistent distance and light resistance.
Reliable Relays: Features Japan's Omron brand relays, ensuring compatibility with various door operator brands.
Surface Mount Technology (SMT): Ensures accuracy and consistency of batch production through stringent quality standards.

Applications for IR-20 Infrared Sensor:

Used in automatic slide doors, gate openers, garage doors, etc.
Consists of a transmitter and receiver, producing an infrared beam.
Suitable for sliding gate openers, swing gate openers, and boom barriers.
Made of high-quality anti-ultraviolet material, ensuring durability.

Specification:

Power Supply: 12/24(VAC/VDC)
Max. Range: Up to 20 meters (indoor or outdoor)
Operating Temperature: -10℃ to +60℃
IP Rating: IP65
Material: ABS
Suitable for yard, wall, garden, etc.

Connection Details:

Fix infrared Photo Beam Eye Sensor on both sides of the automatic door.
Transmitting and receiving parts should be on the same horizontal line for stability and reliability.

The JUTAI IR-20M Infrared Beam Sensor offers exceptional reliability and performance, making it a top choice for various detection applications.

Advantages and Features

Feature	Description
Versatile Integration	Integrates seamlessly with all door control systems, ensuring compatibility and ease of use.
Flexible Mounting Options	Simplifies installation with adaptable mounting, including door edge integration.
Automatic Door Safety	Provides reliable safety measures for automatic doors and gates.
Wide Application Range	Suitable for high-speed doors, sectional doors, rolling doors, vertical closing telescopic doors, and freight elevators.
Accurate Detection	Through-beam safety light curtains detect people or objects passing through, preventing accidents.
Output Options	Offers versatile output methods such as NO/NC and COM.
Efficient Operation	Low working current of <20mA at DC12V and a working voltage range of DC12-24V.
Blanking Functionality	Advanced Blanking function to prevent unnecessary relay activation.
IP67 Waterproof Rating	Withstands harsh environments with an IP67 rating.

Customizable JUTAI Automatic Gate Photocell IR Beams For Gates

Technical parameter

Feature	Specification
Power Supply	12-24VAC/VDC
Max. Range	20 Meters
Operating Temperature	-10 to +60°C
Max. TX Working Current	25mA
Max. RX Working Current	35mA
Max. Relay Contact	500mA at 48VAC/VDC
IP Rating	IP65 with rubber

Connection Details of JUTAI IR-20
Customizable JUTAI Automatic Gate Photocell IR Beams For Gates

To install the IR-20M photocell, please adhere to the following step-by-step instructions:

Access the Interior:
- Lift the front panel of the photocell to access its interior components.
Cable Insertion and Base Fixation:
- Insert the cables into their designated housing slots and firmly fix the base of the photocell to the wall.
Mounting on Wall or Metal Surface:
- If mounting on a wall, drill three 5 ø holes and insert suitable screw anchors.
- For mounting on metal surfaces, drill three 3 ø holes for self-tapping screws.
Make Connections:
- Connect the necessary cables and power the photocell with a voltage ranging between 12 and 24V DC/AC.
Ensure Proper Positioning:
- Verify proper positioning, alignment, and connection of the photocell.
- The red LED on the receiver should remain off if everything is correctly configured.
- When the infrared beam is interrupted, the red LED will illuminate.
Cover with Front Panel:
- Once connections are verified, cover the photocell with the front panel.
- Insert it firmly until it stops, and then securely close it.
Test System:
- Test the system by interrupting the infrared beam multiple times to ensure proper relay response.
Secure Front Panel:
- Finally, secure the front panel in place using the provided screws.

By diligently following these steps, you can ensure the proper installation and functioning of the IR-20M photocell.

Customizable JUTAI Automatic Gate Photocell IR Beams For Gates

Here are the installation guidelines for the JUTAI IR-20 20 meters wired infrared photocell:

Prepare Installation Site: Choose a suitable location free from obstructions for optimal coverage and detection.
Mounting Position: Install the infrared photocell at a height and angle that maximizes coverage and detection range. Ensure a stable and secure mounting surface.
Wiring Connections: Connect the wires according to the provided diagram or manual, ensuring proper insulation and secure connections.
Power Supply: Provide a stable power supply within the specified voltage range (typically 12-24V DC). Double-check polarity and voltage to prevent damage.
Alignment and Testing: Align the infrared lamps to face each other and meet detection requirements. Test by obstructing the beam and verifying relay response.
Fine-Tuning: Fine-tune alignment and sensitivity settings if necessary to optimize performance and minimize false alarms.
Secure Installation: Once confirmed, securely fasten the photocell using provided hardware. Ensure all connections are tight and protect the unit from environmental factors.

Following these guidelines ensures top-tier reliability and performance, providing unparalleled security and convenience with the JUTAI IR-20 20 meters wired infrared photocell.

JUTAI Photocell Beam Sensors Ordering Information
After several years of precipitation and development, we have developed a full range of infrared product groups, ranging from 20 meters wired model, to 30 meters wireless model, 7 meters reflected infrared sensor, and Curtain Photocell groups. For specific information, please refer to our ordering information list.
